Package mechanical data

STLED316S

2/4

Package mechanical data

In order to meet environmental requirements, ST offers these devices in ECOPACK®

packages. These packages have a Lead-free second level interconnect. The category of

second level interconnect is marked on the package and on the inner box label, in

compliance with JEDEC Standard JESD97. The maximum ratings related to soldering

conditions are also marked on the inner box label. ECOPACK is an ST trademark.

DIM.

mm.

inch

MIN.

TYP

MAX.

MIN.

TYP.

MAX.

A

2.35

2.65

0.093

0.104

A1

0.1

0.30

0.004

0.012

B

0.33

0.51

0.013

0.020

C

0.23

0.32

0.009

0.013

D

15.20

15.60

0.598

0.614

E

7.4

7.6

0.291

0.299

e

1.27

0.050

H

10.00

10.65

0.394

0.419

h

0.25

0.75

0.010

0.030

L

0.4

1.27

0.016

0.050

k0°

8°

0°

8°

ddd

0.100

0.004

SO-24 MECHANICAL DATA

0070769C
