ISFM1075

eq IXFN100N50P

N-Channel MOSFET

www.iscsemi.com

3

PACKAGE DIMENSIONS (UNIT: mm):

PRODUCT DISCLAIMER

ISC reserves the rights to make changes of the content herein the datasheet at any time without

notification. The information contained herein is presented only as a guide for the applications of our

products.

ISC products are intended for usage in general electronic equipment. The products are not designed for

use in equipment which require specialized quality and/or reliability, or in equipment which could have

applications in hazardous environments, aerospace industry, or medical field. Please contact us if you

intend our products to be used in these special applications.

ISC makes no warranty or guarantee regarding the suitability of its products for any particular purpose,

nor does ISC assume any liability arising from the application or use of any products, and specifically

disclaims any and all liability, including without limitation special, consequential or incidental damages.

DIM

Millimeter

min

max

A

31.40

31.60

B

7.70

8.10

C

4.20

4.40

D

4.20

4.40

E

4.10

4.40

F

14.90

15.10

G

30.10

30.30

H

38.00

38.40

J

12.00

12.60

K

9.35

9.65

L

0.74

0.84

M

12.30

12.70

N

24.40

25.00

0

1.90

2.10

P

2.92

3.32

Q

26.60

27.00

R

3.80

4.20

S

4.95

5.45

T

23.70

24.30

U

0

0.10

V

3.50

5.50

W

20.15

20.45

Z

2.50

2.70
