UAS24V

Advance

LINEAR INTEGRATED CIRCUIT

UNISONIC TECHNOLOGIES CO., LTD

3 of 4

www.unisonic.com.tw

QW-R101-052.a



ABSOLUTE MAXIMUM RATING

PARAMETER

SYMBOL

RATINGS

UNIT

Input Voltage

Vcc

80

V

Output Current

IO

0.055

A

Operating Temperature

TJ

-40 ~ +150

C

Storage Temperature

TSTG

-40 ~ +150

C

Note: Absolute maximum ratings are those values beyond which the device could be permanently damaged.

Absolute maximum ratings are stress ratings only and functional device operation is not implied.



ELECTRICAL CHARACTERISTICS (All voltage referenced to GND unless otherwise specified)

Internal Res

=10kΩ

PARAMETER

SYMBOL

TEST CONDITIONS

MIN

TYP

MAX

UNIT

Power Supply Current

ICC

VCC=30V, Io=0

0.3

0.6

0.825

mA

VCC=80V, Io=0

0.28

5.6

7.7

mA

Output Voltage

VOUT

VCC=30V, IOUT=20mA

22.8

24

25.2

V

VCC=40V, IOUT=40mA

22.8

24.2

25.2

V

VCC=80V, IOUT=20mA

22.8

24.5

25.2

V

Internal Res

=20kΩ

PARAMETER

SYMBOL

TEST CONDITIONS

MIN

TYP

MAX

UNIT

Power Supply Current

ICC

VCC=30V

0.15

0.3

0.41

mA

VCC=80V

1.4

2.8

3.85

mA

Output Voltage

VOUT

VCC=30V, IOUT=20mA

22.8

24

25.2

V

VCC=40V, IOUT=40mA

22.8

24.1

25.2

V

VCC=80V, IOUT=20mA

22.8

24.4

25.2

V
