Nexperia
PUSB3FS4
Extremely low capacitance unidirectional ESD protection diode array
9. Soldering
SOT1176-1
Footprint information for reflow soldering of DFN2510A-10 package
solder land plus solder paste
occupied area
solder land
solder paste deposit
solder resist
Hx
By
Hy
0.05
C
P
D
0.05
Ay
Dimensions in mm
Ay
By
C
D
Hy
1.25
0.3
0.475
0.2
P
0.5
1.5
Hx
2.45
Generic footprint pattern
Refer to the package outline drawing for actual layout
sot1176-1_fr
recommended stencil thickness: 0.1 mm
Fig. 2. Reflow soldering footprint for DFN2510A-10 (SOT1176-1)
PUSB3FS4_SDS
All information provided in this document is subject to legal disclaimers.
©
Nexperia B.V. 2023. All rights reserved
Short data sheet
8 February 2023
4 / 7
