13. Package Outline Drawing

The package outline drawings are appended at the end of this document and are accessible from the link below. The package information is

the most current data available.

www.idt.com/document/psc/48-vfqfpn-package-outline-drawing-60-x-60-x-090-mm-body-epad-42-x-42-mm-040mm-pitch-ndg48p2

14. Special Notes: NDG 48-VFQFPN Package Assembly

Unopened dry packaged parts have a one-year shelf life.

The HIC indicator card for newly-opened dry packaged parts should be checked. If there is any moisture content, the parts must be baked for

a minimum of 8 hours at 125˚C within 24 hours prior to the assembly reflow process.

15. Marking Diagrams

IDTP9242

-R3NDGI

#YYWW$

LOT



Line 1: Company name and part number.



Line 2: -R3 is part of the part number, which is followed by the package code.



Line 3: “YYWW” is the last two digits of the year and two digits for the week that the part

was assembled. # is the device step. “$” denotes the mark code.

IDTP9242

-RBNDGI

#YYWW$

LOT



Line 1: Company name and part number.



Line 2: -RB is part of the part number, which is followed by the package code.



Line 3: “YYWW” is the last two digits of the year and two digits for the week that the part

was assembled. # is the device step. “$” denotes the mark code.
