P9221-R3 Fiches technique(PDF) 27 Page - Renesas Technology Corp

No de pièce P9221-R3
Description  15W Wireless Charging Receiver with Bi-directional Data Communication
PDF  46 Pages
Scroll/Zoom Zoom In 100%  Zoom Out
Fabricant  RENESAS [Renesas Technology Corp]
Site Internet  http://www.renesas.com
Logo RENESAS - Renesas Technology Corp

P9221-R3 Fiches technique(HTML) 27 Page - Renesas Technology Corp

Back Button P9221-R3 Datasheet HTML 23Page - Renesas Technology Corp P9221-R3 Datasheet HTML 24Page - Renesas Technology Corp P9221-R3 Datasheet HTML 25Page - Renesas Technology Corp P9221-R3 Datasheet HTML 26Page - Renesas Technology Corp P9221-R3 Datasheet HTML 27Page - Renesas Technology Corp P9221-R3 Datasheet HTML 28Page - Renesas Technology Corp P9221-R3 Datasheet HTML 29Page - Renesas Technology Corp P9221-R3 Datasheet HTML 30Page - Renesas Technology Corp P9221-R3 Datasheet HTML 31Page - Renesas Technology Corp Next Button
Zoom Inzoom in Zoom Outzoom out
 27 / 46 page
background image
P9221-R3 Datasheet
© 2017 Integrated Device Technology, Inc.
27
October 20, 2017
Figure 26. State Diagram for Reading User Data Received from the P9242-R3
Read the incoming user data
registers 0058HEX and 0059HEX
Yes
Set bit 4 of register 0056HEX to “1”
to clear the received data flag
Did the INT pin transition
from HIGH to LOW and is
bit 4 of register 0034HEX
set to “1”?
Set bit 5 of register 004EHEX to “1”
to reset the INT pin
