10

Package information

In order to meet environmental requirements, ST offers these devices in different grades of ECOPACK packages,

depending on their level of environmental compliance. ECOPACK specifications, grade definitions and product

status are available at: www.st.com. ECOPACK is an ST trademark.

10.1

SO-8W package information

Table 10. SO-8W package dimensions

Symbol

Dimensions (mm)

Min.

Typ.

Max

A

2.34

2.64

A1

0.1

0.3

b

0.3

0.51

c

0.2

0.33

D(1)

5.64

6.05

e

1.27 BSC

E1

7.39

7.59

E

10.11

10.52

L

0.61

0.91

h

0.25

0.76

Ɵ

0°

8°

aaa

0.25

bbb

0.25

ccc

0.1

1. Dimension “D” does not include mold flash, protrusions or gate burrs. Mold flash, protrusions or gate burrs shall not exceed

0.15 mm per side.

STGAP2GS

Package information

DS14152 - Rev 1

page 13/20
