Round Blue LED Lamp (3mm)

OVLAB6CB8

Absolute Maximum Ratings

Storage Temperature Range

-40 ~ +100 °C

Operating Temperature Range

-40 ~ +95 °C

Reverse Voltage

5 V

Continuous Forward Current

25 mA

Peak Forward Current (10% Duty Cycle, 1KHz)

100 mA

Power Dissipation

105 mW

260°C

Note:

1.

Solder time less than 3 seconds at temperature extreme.

Electrical Characteristics

SYMBOL

PARAMETER

MIN

TYP

MAX

UNITS

CONDITIONS

Luminous Intensity

390

600

----

mcd

Forward Voltage

----

3.6

4.2

V

Forward Voltage

1.7

----

2.5

V

Reverse Current

----

----

100

µA

D

Dominant Wavelength

465

470

475

nm

2 ½H-H

50% Power Angle

----

65

----

deg

Orders for OVLAB6CB8 may be filled with any or all bins contained as below.

Important Notes:

1. All ranks will be included per delivery, rank ratio will be based on the chip distribution.

2. To designate luminous intensity ranks, please contact OPTEK.

3. Pb content <1000PPM.

1100

770

S

550

R

390

Q Luminous intensity is

at Q bin or above.

465

470

475

Dominant Wavelength (nm)

X4

X5

Rank

V8

V9

V10

V11

V12

V13

Voltage (V)

3.0–3.2

3.2–3.4

3.4–3.6

3.6–3.8

3.8–4.0

4.0–4.2
