OUTLINE DIMENSIONS

0.50

0.40

0.30

0.50

BSC

BOTTOM VIEW

TOP VIEW

PIN 1

INDICATOR

EXPOSED

PAD

SEATING

PLANE

0.05 MAX

0.02 NOM

0.20 REF

COPLANARITY

0.08

0.30

0.25

0.18

5.10

5.00 SQ

4.90

0.80

0.75

0.70

FOR PROPER CONNECTION OF

THE EXPOSED PAD, REFER TO

THE PIN CONFIGURATION AND

FUNCTION DESCRIPTIONS

SECTION OF THIS DATA SHEET.

0.25 MIN

3.75

3.60 SQ

3.55

COMPLIANT TO JEDEC STANDARDS MO-220-WHHD-5.

PIN 1

INDIC ATOR AREA OPTIONS

(SEE DETAIL A)

DETAIL A

(JEDEC 95)

Figure 48. 32-Lead Lead Frame Chip Scale Package [LFCSP]

5 mm × 5 mm Body and 0.75 mm Package Height

(CP-32-12)

Dimensions shown in millimeters

ORDERING GUIDE

Model1

Temperature Range

Package Description

Package Option

ADP1850ACPZ-R7

−40°C to +85°C

32-Lead Lead Frame Chip Scale Package [LFCSP]

CP-32-12

ADP1850SP-EVALZ

Evaluation Board in Single-Phase Mode with 14 A Output

ADP1850DP-EVALZ

Evaluation Board in Dual-Phase Mode with 50 A Output

1 Z = RoHS Compliant Part.
