Data Sheet

ADP5014

Rev. A | Page 33 of 34

FACTORY PROGRAMMABLE OPTIONS

FACTORY DEFAULT OPTIONS

Table 13 lists the factory default options programmed into the ADP5014 when the device is ordered (see the Ordering Guide). To order

the device with options other than the default options, contact your local Analog Devices sales or distribution representative.

Table 13. Factory Default Options

Option

Default Value

Channel 1 Output Voltage

Adjustable output

Channel 2 Output Voltage

Adjustable output

Channel 3 Output Voltage

Adjustable output

Channel 4 Output Voltage

Adjustable output

PWRGD Pin Output

Monitor all Channel 4 outputs (enabled by the CFG2 configuration)

Output Discharge Function

Enabled for all four buck regulators

Hiccup Detection

Hiccup protection enabled for overcurrent events
