PL611-07

47745 Fremont Blvd., Fremont, California 94538 Tel (510) 492-0990 Fax (510) 492-0991 www.phaselink.com Rev 08/17/05 Page 2

ELECTRICAL SPECIFICATIONS

ABSOLUTE MAXIMUM RATINGS

PARAMETERS

SYMBOL

MIN.

MAX.

UNITS

Supply Voltage Range

4.6

V

Input Voltage Range

V

Output Voltage Range

V

Soldering Temperature (Green package)

260

°C

Data Retention @ 85

°C

10

Year

Storage Temperature

-65

150

°C

Ambient Operating Temperature

-40

85

°C

Exposure of the device under conditions beyond the limits specified by Maximum Ratings for extended periods may cause permanent damage to the device

and affect product reliability. These conditions represent a stress rating only, and functional operations of the device at these or any other conditions above

the operational limits noted in this specification is not implied.

AC SPECIFICATIONS

PARAMETERS

CONDITIONS

MIN.

TYP.

MAX.

UNITS

Crystal Input Frequency(XIN)

Fundamental Crystal

10

30

MHz

Input (FIN) Frequency

100

MHz

Input (FIN) Signal Amplitude

Internally AC coupled

0.9

VDD

Vpp

Settling Time

At power-up (after VDD increases over 1.62V)

10

ms

15pF Load, 10/90%VDD, Standard drive

2.5

3.5

ns

Output Rise Time

15pF Load, 10/90%VDD, High drive

1.0

1.5

ns

15pF Load, 90/10%VDD, Standard drive

2.5

3.5

ns

Output Fall Time

15pF Load, 90/10%VDD, High drive

1.0

1.5

ns

Duty Cycle

At VDD/2

45

50

55

%

Period Jitter, peak-to-peak*

(measured from 10,000 samples)

With capacitive decoupling between VDD and

GND. Operating only one output.

70

ps

* Note: Jitter performance depends on the programming parameters.
