Data Sheet
HMC524ALC3B
Rev. A | Page 21 of 24
THEORY OF OPERATION
The HMC524ALC3B is a compact GaAs MMIC I/Q mixer in a
leadless RoHS compliant SMT ceramic package. This device is
either an image reject mixer or a single-sideband upconverter.
When used as an image reject mixer, the HMC524ALC3B
downconverts radio frequencies between 22 GHz and 32 GHz to
intermediate frequencies between dc and 4.5 GHz.
When used as single-sideband upconverter, the HMC524ALC3B
upconverts IF between dc and 4.5 GHz to RF between 22 GHz
and 32 GHz
