7 / 26 page

Data Sheet

ADL5920

Rev. B | Page 7 of 26

Parameter1

Test Conditions/Comments

Min

Typ

Max

Unit

TEMPERATURE COMPENSATION

TADJI

Input Voltage Range

Input Bias Current

VTADJI = 1 V

µA

Input Resistance

kΩ

VOLTAGE REFERENCE

VREF

Output Voltage

TA = 25°C, load resistance (RL) = 10 kΩ

2.5

Small Signal Output Impedance

3.1

Ω

Current Capability

Source

9.8

Sink

4.6

TEMPERATURE REFERENCE

VTEMP

Output Voltage

TA = 25°C, RL ≥ 10 kΩ

1.38

Temperature Coefficient

−40°C ≤ TA ≤ +85°C, RL ≥ 10 kΩ

4.5

mV/°C

POWER-DOWN INTERFACE AND

TEMPERATURE COMPENSATION

Pin PWDN/TADJS

Voltage Level

To Enable

1.2

To Disable

1.5

Enable Time

PIN = 10 dBm, PWDN/TADJS at 50% to output voltage at

90%, 10 nF on CRMSF and CRMSR

µs

Disable Time

PIN = 10 dBm, PWDN/TADJS at 50% to output voltage at

10%, 10 nF on CRMSF and CRMSR

µs

Input Bias Current

VTADJS = 2.5 V

µA

Input Resistance

kΩ

POWER SUPPLY

VPOS1, VPOS2, VPOS3

Supply Voltage

4.9

5.1

Quiescent Current

PWDN/TADJS low

130

160

200

PWDN/TADJS high

When referring to a single function of a multifunction pin in the parameters, only the portion of the pin name that is relevant to the specification is listed. For full pin

names of multifunction pins, refer to the Pin Configuration and Function Descriptions section.
