1 / 10 page

Features

•

175 °C maximum operation junction temperature

•

High surge current capability

•

ECOPACK2 compliant component

Application

•

DC/DC converters

•

Freewheeling diodes

•

LED Lighting

Description

The STTH602CSF has been developed for applications requiring an optimized VF

and reverse recovery characteristics.

These characteristics make it ideal for use in secondary rectification functions, such

as DC/DC converters or lighting applications.

Product status link

STTH602CSF

Product summary

Symbol

Value

IF(AV)

2 X 3 A

VRRM

200 V

trr(max)

24 ns

Tj (max.)

175 °C

VF (typ.)

0.80 V

200 V, dual 3 A ultrafast rectifier

STTH602CSF

Datasheet

DS13550 - Rev 1 - November 2020

For further information contact your local STMicroelectronics sales office.

www.st.com
