ADAR2001
Data Sheet
Rev. 0 | Page 4 of 39
Parameter
Test Conditions/Comments
Min
Typ Max Unit
Switching Time
Multiplier Band Sleep to Active
50
ns
Multiplier Band Switch
Using ready mode
10
ns
PA Sleep to Active
50
ns
Channel to Channel Switch
Using ready mode, first channel off to second channel on
2
ns
DIGITAL INPUT LOGIC LEVELS
Logic Low
0
0.3
V
Logic High
1
1.8
V
DIGITAL OUTPUT LOGIC LEVELS
Logic Low
0
0.4
V
Logic High
1.4
1.8
V
VREG OUTPUT
1.8
V
POWER SUPPLY
Analog
Supply Voltage Range (VPOS1, VPOS3, VPOS4, VPOS5)
2.25 2.5
2.75
V
Current Consumption
One channel active
180
mA
Chip disabled
10
mA
Power Consumption
One channel active
450
mW
Chip disabled
25
mW
Digital
Supply Voltage Range (VPOS2)
1.6
1.8
2
V
Current Consumption
Chip enabled
25
µA
Power Consumption
Chip enabled
45
µW
