 10 / 15 page
background image
10
PDS-001540 Rev 15
© 2016 Luminus Devices, Inc. - All Rights Reserved
Luminus Devices, Inc. • T 978.528.8000 • www.luminus.com
175 New Boston Street • Woburn, MA 01801
Typical Radiation Patterns
Thermal Resistance
TypicalThermal Resistance :
R
j-c
1
0.5 ºC/W
R
j-b
1
1.2 ºC/W
R
j-hs
2
1.4 ºC/W
Note 1: Thermal resistance values are based on
FEA model results correlated to
measured Rθj-hs data.
Note 2: Thermal resistance is measured using a
SAC305 solder, a Bergquist Al-clad
MCPCB, and eGraf 1205 thermal
interface material.
Typical Polar Radiation Pattern for White
Typical Angular Radiation Pattern for White
Window
Ceramic Substrate
Tj
Window Frame
Die Junction
Heat sink
Ths
Tb
Al coreboard
Tc
Window
Ceramic Substrate
Tj
Window Frame
Die Junction
Heat sink
Ths
Tb
Al coreboard
Window
Ceramic Substrate
Tj
Window Frame
Die Junction
Heat sink
Ths
Tb
Al coreboard
Window
Ceramic Substrate
Tj
Window Frame
Die Junction
Heat sink
Ths
Tb
Al coreboard
Tc
-30°
-60°
120°
150°
210°
240°
60°
30°
-120%
-100%
-80%
-60%
-40%
-20%
0%
20%
40%
60%
80%
100%
120%
0%
20%
40%
60%
80%
100%
120%
-80
-60
-40
-20
0
20
40
60
80
Anglular Displacement (Degrees)
SBT-90 Product Datasheet
