IS25LP032D
IS25WP032D
Integrated Silicon Solution, Inc.- www.issi.com
54
Rev. A12
08/04/2020
Figure 8.18 Block Erase (32K) Sequence In SPI Mode
Instruction = 52h
23
CE #
SCK
SI
3
2
SO
1
0
3-byte Address
High Impedance
22
21
...
0
1
2
3
4
5
6
7
8
9
10
...
28
29
30
31
Mode 3
Mode 0
Figure 8.19 Block Erase (32K) Sequence In QPI Mode
52h
CE#
SCK
IO[3:0]
3-byte Address
0
1
2
3
4
5
6
7
Mode 3
Mode 0
23:20 19:16 15:12 11:8
7:4
3:0
