background image
General Purpose Transistors
MAXIMUM RATINGS
Rating
Symbol
Value
Unit
Collector–Emitter Voltage
V CEO
50
V
Collector–Base Voltage
VCBO
60
V
Emitter–Base Voltage
VEBO
7.0
V
Collector Current — Continuous
I C
150
mAdc
Collector power dissipation
PC
0.2
W
Junction temperature
Tj
150
C
Storage temperature
Tstg
-55 ~+150
C
h FE values are classified as follows:
Q
R
S
hFE
120~270
180~390
270~560
2
EMITTER
3
COLLECTOR
1
BASE
*
NPN Silicon
FEATURE
Low Cob,Cob=2pF(Typ.).
Epitaxial planar type.
PNP complement : FTA1576
DEVICE MARKING AND ORDERING INFORMATION
Device
Marking
Shipping
FTC4081-Q
BQ
3000/Tape&Reel
FTC4081-Q
BQ
10000/Tape&Reel
FTC4081-R
BR
3000/Tape&Reel
FTC4081-R
BR
10000/Tape&Reel
FTC4081-S
BS
3000/Tape&Reel
FTC4081-S
BS
10000/Tape&Reel
2008. 4. 20
1/5
SEMICONDUCTOR
TECHNICAL DATA
FTC4081
Revision No : 0
1
3
2
SC-70 / SOT– 323
