ADP2291
Rev. 0 | Page 5 of 20
ABSOLUTE MAXIMUM RATINGS
Table 2.
Parameter
Rating
IN, DRV1, CS, CHG, to GND
−0.3 V to +13.5 V
BAT, ADJ, TIMER to GND
−0.3 V to (VIN + 0.3 V)
Operating Ambient Temperature
−40°C to +85°C
Operating Junction Temperature
−40°C to +125°C
θJA, 2-layer MSOP-8
220ºC/W
θJA, 4-layer MSOP-8
158ºC/W
θJA, 2-layer LFCSP-8
62ºC/W
θJA, 4-layer LFCSP-8
48ºC/W
Storage Temperature
−65°C to +150°C
Lead Temperature Range Soldering
(10 sec)
300°C
Stresses above those listed under Absolute Maximum Ratings
may cause permanent damage to the device. This is a stress
rating only and functional operation of the device at these or
any other condition s above those indicated in the operational
section of this specification is not implied. Exposure to absolute
maximum rating conditions for extended periods may affect
device reliability. Absolute maximum ratings apply individually
only, not in combination. Unless otherwise specified all other
voltages referenced to GND.
1 Pulling current from the DRV pin by driving it below ground, while VIN is
applied, may cause permanent damage to the device.
ESD CAUTION
ESD (electrostatic discharge) sensitive device. Electrostatic charges as high as 4000 V readily accumulate on
the human body and test equipment and can discharge without detection. Although this product features
proprietary ESD protection circuitry, permanent damage may occur on devices subjected to high energy
electrostatic discharges. Therefore, proper ESD precautions are recommended to avoid performance
degradation or loss of functionality.
