Package information
In order to meet environmental requirements, ST offers these devices in different grades of ECOPACK packages,
depending on their level of environmental compliance. ECOPACK specifications, grade definitions and product
status are available at: www.st.com. ECOPACK is an ST trademark.
8.1
QFN-24 EP (4x4) package information
Figure 9. QFN-24 EP (4x4) package information
PLANE
SEATING
0.08 C
C
TOP VIEW
SIDE VIEW
BOTTOM VIEW
Pin#1 ID
D
e
D2
b
L
STUSB4500L
Package information
DS13102 - Rev 1
page 21/31
