Data Sheet

AS02804PR-N50-R

Introducing the N50 Mini Speaker Series from PUI Audio. High-grade

neodymium magnetic motors are employed in each N50 Series speaker to create

the highest output possible, in the smallest form factor.

The 28mm diameter AS02804PR-N50-R features a paper cone and foam

surround for classic HiFi sound quality. Four openings on the back plate create

forced-air cooling to dissipate heat from the voice coil.

Features:

•

Paper cone and foam surround

•

High 76 dB output at 3W/1m

•

N50 neodymium motor

•

Only 7.5mm thick

•

2mm of excursion

Specifications

Parameters

Values

Units

Rated Input Power

3

Watts

Max Input Power

4

Watts

Impedance

4 ± 15%

Ohms

Sensitivity (SPL @ 3W/1m)

(800, 1000, 1200, and 1500 Hz)

76.5 ± 3

dBA

Distortion (Max @ 1W, 1 kHz)

<5%

Resonant Frequency

350 ± 20%

Hz

Frequency Range

250 ~ 20,000

Hz

Housing Material

ABS

Magnet Material

NdFeB

Weight

10.8

Grams
