TECHNICAL DATA SHEET
ATE-R6
<FOR TOPLITE COB MODULE>
3 / 9
A/1
ATE-R6 SERIES
Revision issued in 2014.
3-2. ELECTRICAL-OPTICAL CHARACTERISTICS
(Tc=25℃)
**
PARAMETER
SYMBOL
CONDITION
MIN.
TYP.
MAX.
UNIT
common
Forward Voltage *1
VF
IF=300mA
8.4
9.0
10
V
Beam Angle
Deg
—
120
—
Deg
W
**
Color Temp.
TC
IF=300mA
2870
3045
3220
K
**
Color Rendering Index *3
Ra
80
—
—
—
W1
Luminous Flux *2
Φ
252
266
—
lm
Luminous Efficiency
η
90
95
—
lm/W
W2
Luminous Flux *2
Φ
269
280
—
lm
Luminous Efficiency
η
96
100
—
lm/W
D
**
Color Temp.
TC
IF=300mA
4745
5028
5311
K
**
Color Rendering Index *3
Ra
80
—
—
—
D1
Luminous Flux *2
Φ
280
294
—
lm
Luminous Efficiency
η
100
105
—
lm/W
D2
Luminous Flux *2
Φ
297
308
—
lm
Luminous Efficiency
η
106
110
—
lm/W
C
**
Color Temp.
TC
IF=300mA
6020
6530
7040
K
**
Color Rendering Index *3
Ra
80
—
—
—
C1
Luminous Flux *2
Φ
294
308
—
lm
Luminous Efficiency
η
105
110
—
lm/W
C2
Luminous Flux *2
Φ
310
320
—
lm
Luminous Efficiency
η
111
115
—
lm/W
(Note) Parameters is formulated based on shipping samples
*1. After 20 ms drive, Measurement tolerance: ± 3 %
*2. Monitored by Toplight's 1 m integrating sphere, after 20 ms drive, Measurement tolerance: ± 10 %
*3. Monitored by Toplight's 1 m integrating sphere, after 20 ms drive, Measurement tolerance:± 2
