Parameter

Symbol

Condition

Ratings

Unit

Min.

Typ.

Max.

Power supply current

Working

-

5

8

mA

Output Block

Source

Ron (H)

-

0.7

1.2

Ω

Sink

Ron (L)

-

0.5

0.8

Ω

Source + sink

Ron (H+L)

-

1.2

2

Ω

6V Regulator Block

Regulator voltage

VREG6

5.7

6

6.3

V

Regulator output current

VREG6=6V

10

mA

HB Voltage

HB voltage

HB

I HB=5mA

1.25

V

Hall input pin

Hall sensor input sensitivity

VHN

Zero peak value

(including offset

and hysteresis)

10

20

mV

Analog I/O Section

Analog Input range

0

6.3

V

PWM

PWM PIN Frequency

PWM

21K

25K

28K

Hz

SMIN Block

VPWM High Level Voltage

VPWMH

3.48

3.66

3.84

V

VPWM Low Level Voltage

VPWML

1.71

1.8

1.89

V

FG Output Pin

FG output pin low-level voltage

VFG

-

0.1

0.2

V

Thermal Protection Circuit

Thermal

protection

circuit

operating temperature

TSD

Design target

-

170

-

℃

Temperature hysteresis width

ΔTSD

Design target

-

15

-

℃

Low-Voltage Detection

Low voltage detection voltage

UVLO

3.5

V

1. This current is output of internal LDO. Please do not exceed the maximum value specified.

HM2602
