1 / 8 page

www.p-tec.net

102013 Rev0 JAS

Page 1 of 8

PRODUCT SPECIFICATION

Part Number

PDM8876 series

Details

• 0.76” (19.4mm) Dot Matrix Display

• 8x8 Array

• Available in Common Anode or Cathode

• Emitting Color: Pure Green, Yellow Green,

Yellow, Amber, Orange-Red, Red or Deep

Red

Features

• Low power consumption

• RoHS Compliant

• Gray or Black Face, White Segment

• Easy mounting on PCB or socket

Mechanical Dimensions

Notes:

1. Dimensions in millimeters [inch], and tolerance is ±0.25 [.010] and angle is ±1° unless otherwise noted.

2. Bending

≤ Length*1%

3. All pins are

⌀0.50[.020]±0.1[.004]

4. Specifications subject to change without notice
