SSM2529
Data Sheet
Rev. 0 | Page 50 of 52
APPLICATIONS INFORMATION
Figure 42. Software Mode (with I2C Interface)
Figure 43. Hardware Standalone Mode
SSM2529
ADDR
OUTP
OUTN
100nF
10µF
SPKVDD
(2.5V TO 5.5V)
100nF
DVDD
(1.08V TO 1.98V)
1µF
LDO_OUT
(1.8V)
SPKGND
GND
SA_MODE
2.2k
Ω
2.2k
Ω
SYSTEM
CONTROLLER
IOVDD
(1.8V TO 3.6V)
STDBN
SCL
SDA
AUDIO
PROCESSOR
BCLK
LRCLK
SDATA
MCLK
SSM2529
OUTP
OUTN
100nF
10µF
SPKVDD
(2.5V TO 5.5V)
100nF
DVDD
(1.08V TO 1.98V)
1µF
LDO_OUT
(1.8V)
SPKGND
GND
SA_MODE
SPKVDD
STDBN
BCLK
LRCLK
SDATA
MCLK
SDA
SCL
ADDR
