ULC831
Preliminary
LINEAR INTEGRATED CIRCUIT
UNISONIC TECHNOLOGIES CO., LTD
5 of 7
www.unisonic.com.tw
QW-R104-012..a
ELECT RI CAL CH ARACT ERI ST I CS (Cont .)
(+VS=2.5V, -VS=0V, VCM=+VS/2 and VO=-VS, TA=25°C, unless otherwise noted.)
PARAMETER
SYMBOL
TEST CONDITIONS
MIN
TYP
MAX
UNIT
VCM=0.3V
310
nA
Supply Current
IS
VCM=2.2V
260
nA
VCM=0V
0.5
mV
Input Offset Voltage
VOS
VCM=2.5V
0.5
mV
Input Offset Average Drift
2
µV/°C
VCM Stepped from 0V to 1.4V
75
dB
VCM Stepped from 1.9V to 2.5V
80
dB
Common Mode Rejection Ratio
CMRR
VCM Stepped from 0V to 2.5V
80
dB
Power Supply Rejection Ratio
PSRR
VS=1.8V~5.5V, VCM=0V
95
dB
Large Signal Voltage Gain
AVO
100
dB
IO=500
μA
2.419
V
Output Swing High
VOH
IO=1mA
2.333
V
IO=-500
μA
66
mV
Output Swing Low
VOL
IO=-1mA
133
mV
Source
5.3
mA
Output Current
IOUT
Sink
7.7
mA
Overdrive=10mV
12
μs
Propagation Delay (High to Low)
Overdrive=100mV
5
μs
Overdrive=10mV
28
μs
Propagation Delay (Low to High)
Overdrive=100mV
19
μs
Overdrive=10mV, CL=30pF,
RL=1M
Ω
120
ns
Rise Time
tRise
Overdrive=100mV, CL=30pF,
RL=1M
Ω
120
ns
Overdrive=10mV, CL=30pF,
RL=1M
Ω
85
ns
Fall Time
tFall
Overdrive=100mV, CL=30pF,
RL=1M
Ω
70
ns



Html Pages

1 2 3 4 5 6 7
