LTC6953
13
Rev 0
For more information www.analog.com
Preliminary Technical Data
Advance Product Information Subject to Change
Rev PrA
TIMING DIAGRAMS
tPD-VCO
tSKEW1
IN–
IN+
OUT0+
OUT1+
OUT2+
OUT3+
OUT10+
OUT1–
OUT2–
OUT3–
OUT10–
6953 TD01
OUT0–
tSKEW2
tSKEW3
tSKEW3
AVERAGE ZERO CROSSING TIME OF ALL OUTPUTS
tSKEW0
tR
tF
6953 TD02
80%
20%
Propagation Delay and Output Skew
Differential CML Rise/Fall Times
