SSM4321

Data Sheet

Rev. 0 | Page 6 of 24

ABSOLUTE MAXIMUM RATINGS

Absolute maximum ratings apply at 25°C, unless otherwise noted.

Table 3.

Parameter

Rating

PVDD Supply Voltage

6 V

IOVDD Supply Voltage

3.6 V

Input Voltage

PVDD

Common-Mode Input Voltage

PVDD

Storage Temperature Range

−65°C to +150°C

Operating Temperature Range

−40°C to +85°C

Junction Temperature Range

−65°C to +165°C

Lead Temperature (Soldering, 60 sec)

300°C

ESD Susceptibility

4 kV

Stresses above those listed under Absolute Maximum Ratings

may cause permanent damage to the device. This is a stress

rating only; functional operation of the device at these or any

other conditions above those indicated in the operational

section of this specification is not implied. Exposure to absolute

maximum rating conditions for extended periods may affect

device reliability.

THERMAL RESISTANCE

Junction-to-air thermal resistance (θJA) is specified for the

worst-case conditions, that is, a device soldered in a printed

circuit board (PCB) for surface-mount packages.

Table 4. Thermal Resistance

Package Type

Unit

16-Ball, 1.74 mm × 1.74 mm WLCSP

665

°C/W

1 The θ

JA specification is measured on a JEDEC standard 4-layer PCB.

ESD CAUTION
