ADL5240

Data Sheet

Rev. A | Page 8 of 28

ABSOLUTE MAXIMUM RATINGS

Table 2.

Parameter

Rating

Supply Voltage (VDD, VCC)

6.5 V

Input Power

AMPIN

16 dBm

DSAIN

30 dBm

Internal Power Dissipation

0.5 W

θJA (Exposed Pad Soldered Down)

36.8°C/W

θJC (Exposed Pad is the Contact)

6.9°C/W

Maximum Junction Temperature

150°C

Lead Temperature (Soldering, 60 sec)

240°C

Operating Temperature Range

−40°C to +85°C

Storage Temperature Range

−65°C to +150°C

Stresses abovethoselisted under AbsoluteMaximumRatings

may cause permanent damageto the device. This is a stress

rating only; functional operation of the device at these orany

other conditions above thoseindicated in the operational

section of this specification is not implied. Exposure to absolute

maximum rating conditions for extended periods may affect

device reliability.

ESD CAUTION
