background image
Data Sheet
ADL5201
Rev. C | Page 25 of 26
Configuration Options for the USB Section
Table 10. Bill of Materials for USB Section
Components
Default Conditions
C31, C62
22 pF (Size 0603)
C49
1000 pF (Size 0603)
C28 to C30, C53 to C55, C57 to C61
0.1 μF (Size 0402)
C47, C50
1 μF (Size 0402)
C52, C56
10 pF (Size 0402)
D6
Green LED (Panasonic LNJ308G8TRA)
J16
USB SMT connector (Hirose Electric UX60A-MB-5ST 240-0003-4)
R39, R49, R50
2 kΩ (Size 0603)
R41
78.7 kΩ (Size 0603)
R40
140 kΩ (Size 0603)
R44, R45
100 kΩ (Size 0603)
R58
0 Ω (Size 0603)
U6
USB microcontroller (Cypress CY7C68013A-56LFXC)
U7
64 kbit EEPROM (Microchip 24LC64-I/SN)
U5
Low dropout regulator (Analog Devices ADP3334ACPZ)
Y2
24 MHz crystal oscillator (AEL Crystals X24M000000S244)
