 8 / 13 page
background image
AD8211
Data Sheet
Rev. C | Page 8 of 13
TIME (1µs/DIV)
200mV/DIV
OUTPUT
2V/DIV
INPUT
Figure 16. Differential Overload Recovery (Rising)
TIME 5µs/DIV)
2V/DIV
0.01/DIV
Figure 17. Settling Time (Falling)
TIME 5µs/DIV)
2V/DIV
0.01/DIV
Figure 18. Settling Time (Rising)
12.0
5.0
–40
TEMPERATURE (°C)
–20
0
20
40
60
80
100
120
140
–30
–10
10
30
50
70
90
110
130
150
8.5
8.0
7.5
7.0
6.5
11.0
11.5
10.5
10.0
9.5
9.0
6.0
5.5
Figure 19. Maximum Output Sink Current vs. Temperature
9.0
4.0
–40
TEMPERATURE (°C)
–20
0
20
40
60
80
100
120
140
8.5
8.0
7.5
7.0
6.5
6.0
5.5
5.0
4.5
Figure 20. Maximum Output Source Current vs. Temperature
5.0
1.0
0
OUTPUT SOURCE CURRENT (mA)
9
4.6
4.2
3.8
3.4
3.0
2.6
2.2
1.8
1.4
123
4567
8
Figure 21. Output Voltage Range vs. Output Source Current
