MLPCH12-R68M-RC Fiches technique(PDF) 1 Page - Allied Components International |
|
|
|||||||||||||||||||||||||||||
MLPCH12-R68M-RC Fiches technique(HTML) 1 Page - Allied Components International |
|
|
1 / 1 page  MLPCH12 High Current Multilayer Inductor MLPCH12-R24M-RC MLPCH12-R47M-RC MLPCH12-R68M-RC MLPCH12-1R0M-RC MLPCH12-1R5M-RC MLPCH12-2R2M-RC 0.24 0.47 0.68 1.0 1.5 2.2 Isat (mA) Typ. (Max) Allied Part Number Inductance (µH) Tolerance (%) Test Freq. (MHz) DCR (Ω ±25%) RoHS 949-356-1780 ALLIED COMPONENTS INTERNATIONAL www.alliedcomponents.com .079±.008 (2.0±0.2) .063±.008 (1.6±0.2) .020±.012 (0.5±0.3) .071±.008 (1.8±0.2) .095±.012 (2.4±0.3) 0.039±.008 (1.0±0.2) Dimensions: Inches (mm) 0.039 (1.0) All specifications subject to change without notice. 2/27/2017 Features • High Saturation current up to 4.0A • Expanded operating temp range • Low DC Resistance • Multilayer Ferrite Construction • Suitable for pick and place Electrical Inductance Range: .24µH to 2.2µH Tolerance: 20% Test Frequency: (L) 3MHz, 200mV Operating Temp: -55ºC to +125ºC (Including self-temperature rise) Isat: Based on Inductance drop 30% from initial value without current Irms: Based on 40°C temp rise above ambient 25°C. Under no condition should the temperature of part exceed 125°C. Resistance to Soldering Heat Test Equipment (L): HP4287A RF Impedance Analyzer DCR: HP4338B Physical Packaging: 3000 pieces per 7 inch reel Marking: None 3500(4200) 2600(3100) 2400(2800) 2200(2600) 1600(1900) 1500(1800) Inductance vs. Frequency Chaaracteristics 0 0.5 1 1.5 2 2.5 3 3.5 4 0 0 0 1 0 0 1 0 1 1 Frequency(MHz) 2R2 R24 R47 R68 1R0 1R5 Inductance vs. DC Current 0 0.5 1 1.5 2 2.5 3 1 10 100 1000 10000 DC Current(mA) 2R2 1R5 1R0 R68 R47 R24 20 20 20 20 20 20 3 3 3 3 3 3 .023 .037 .065 .068 .10 .21 3600(4000) 2500(2900) 2500(2800) 1500(1900) 1500(1800) 1000(1300) MAX Recommended PCB Layout Irms (mA) Typ. (Max) Pre-heat: 150ºC, 1min Solder Composition: Sn/Ag3.0/Cu5.0 Solder Temperature: 260°C ± 5°C Immersion Time: 10Sec ± 1Sec |
