369/429

10-BIT ANALOG TO DIGITAL CONVERTER (ADC)

CHANNEL 12 DATA HIGH REGISTER (D12HR)

R248 - Read/Write

Reset Value: undefined

Bits 7:0 = D12.[9:2]: Channel 12 9:2 bit Data

CHANNEL 12 DATA LOW REGISTER (D12LR)

R249 - Read/Write

Reset Value: xx00 0000

Bits 7:6 = D12.[1:0]: Channel 12 1:0 bit Data

Bits 5:0 = Reserved, forced by hardware to 0.

CHANNEL 13 DATA HIGH REGISTER (D13HR)

R250 - Read/Write

Reset Value: undefined

Bits 7:0 = D13.[9:2]: Channel 13 9:2 bit Data

CHANNEL 13 DATA LOW REGISTER (D13LR)

R251 - Read/Write

Reset Value: xx00 0000

Bits 7:0 = D13.[1:0]: Channel 13 1:0 bit Data

Bits 5:0 = Reserved, forced by hardware to 0.

CHANNEL 14 DATA HIGH REGISTER (D14HR)

R252 - Read/Write

Reset Value: undefined

Bits 7:0 = D14.[9:2]: Channel 14 9:2 bit Data

CHANNEL 14 DATA LOW REGISTER (D14LR)

R253 - Read/Write

Reset Value: xx00 0000

Bits 7:0 = D14.[1:0]: Channel 14 1:0 bit Data

Bits 5:0 = Reserved, forced by hardware to 0.

CHANNEL 15 DATA HIGH REGISTER (D15HR)

R254 - Read/Write

Reset Value: undefined

Bits 7:0 = D15.[9:2]: Channel 15 9:2 bit Data

CHANNEL 15 DATA LOW REGISTER (D15LR)

R255- Read/Write

Reset Value: xx00 0000

Bits 7:0 = D15.[1:0]: Channel 15 1:0 bit Data

Bits 5:0 = Reserved, forced by hardware to 0.

Note: If only 8-bit accuracy is required, each Data

High Register can be used to get the conversion

result, ignoring the corresponding DxLR register

content.

D12.9 D12.8 D12.7 D12.6 D12.5 D12.4 D12.3 D12.2

D12.1 D12.0

D13.9 D13.8 D13.7 D13.6 D13.5 D13.4 D13.3 D13.2

D13.1 D13.0

D14.9 D14.8 D14.7 D14.6 D14.5 D14.4 D14.3 D14.2

D14.1 D14.0

D15.9 D15.8 D15.7 D15.6 D15.5 D15.4 D15.3 D15.2

D15.1 D15.0
